Description
CFV235 Mesh is a new type of PC case with an innovative Central Floating Ventilation (CFV) design. It separates the power supply compartment from the main chamber, using the open space between them for enhanced cooling through additional airflow, while maintaining compactness without compromising improved thermal performance. Combined with the front panel 3-in-1 module—integrating a mesh grille, two 160 mm ARGB PWM fans, and a dust filter into a single pre-assembled unit—CFV235 Mesh delivers airflow that exceeds standard case capabilities.
True Floating Structural Separation
Traditional case designs place the power supply—the main heat source—and critical components within the same enclosed space, limiting airflow access to only the top, front, and rear panels. Central Floating Ventilation separates the PSU chamber from the main compartment with a structural air gap, allowing greater freedom and directional control of airflow. This open architectural design also gives the CFV235 series a unique, progressive appearance.
270° Air Access in Floating Chamber
The floating space in the CFV235 series forms a fully three-dimensional discrete cavity suspended within the chassis. A spacious, unobstructed 270° air intake ensures superior ventilation compared to enclosed layouts, precisely where it's needed most.
Plug and Play with One Module
The 3-in-1 front panel module—integrating a dust filter, two pre-installed 160 mm ARGB PWM fans, and a mesh panel into a single pre-assembled unit—enables maintenance in a single step. The magnetic dust filter attaches to the frame, two 160 mm ARGB PWM fans (pre-installed) mount into the frame pre-attached to the front mesh panel, and the front mesh panel with its integrated frame forms a complete, ready-to-install component.
Smart Pogo Pin Connector
A spring-loaded pin on the 3-in-1 module provides physical contact with the corresponding connector built into the CFV chassis, minimizing cable clutter while maintaining reliable power and signal connections.
Pre-Installed Dual 160 mm ARGB PWM Fans
Get your build up and running immediately: two 160 mm ARGB PWM fans come pre-installed and integrated into the 3-in-1 front panel module, saving setup time and delivering optimal cooling right out of the box.
Rainbow Between Them
The Aurora light strip illuminates the interior of the Central Floating Ventilation structure from within, highlighting this innovative feature as a reimagined architectural element. It comes included and attaches magnetically for convenience and ease of use.
Light. Speed.
CFV235 Mesh features a built-in universal fan hub that seamlessly coordinates PWM-controlled fan speeds and RGB lighting. This allows RGB control without software or synchronization with motherboard software.
Dual Magnetic Filtration
Magnetic dust filters on the top and base of the Central Floating Ventilation structure actively prevent dust and debris buildup, maintaining clean and uninterrupted airflow without compromising the floating design.
Vertical Space Efficiency
Positioning the central floating ventilation channel along the vertical axis avoids increasing overall width, preserving compactness.
Spatial Engineering
A 38 mm clearance behind the motherboard tray improves cable management, providing extra space for routing and concealing cables of various thicknesses. Five adjustable Velcro straps offer versatile options for securing and neatly organizing cables.
Architectural Strength
A 1.5 mm thick steel frame reinforces the chassis, maintaining structural integrity even with the floating central ventilation design. The result is a bold, open architecture that remains rigid, reliable, and ready for high-performance builds.
Universal Compatibility
Compatible with motherboards featuring offset connectors and supporting GPUs up to 400 mm in length, the CFV235 Mesh case is designed for future gaming systems. The cover serves three functions: directing airflow, simplifying cable routing, and acting as a GPU support bracket. Its position can be optimized based on motherboard specifications, maximizing space utilization, reducing cable clutter, and enhancing system stability.
Directed Airflow
The cable cover also acts as an airflow guide, ensuring precise cooling for the CPU and GPU where it's needed most.
Cooling Capacity
The CFV235 Mesh case supports up to three 120 mm or two 140 mm fans on top, three 120 mm fans at the bottom of the main chamber, two 160 mm fans at the front, and one 120 mm fan at the rear (shipped with two 160 mm front fans and one 120 mm ARGB PWM rear fan). Up to 360 mm top-mounted radiators are supported for liquid cooling.
Peripherals
CFV235 Mesh includes USB 3.2 Gen 2x2 Type-C (20 Gbps) x1, USB 3.0 Type-A x2, and a 4-pin audio jack for connecting various devices.
Full House
With support for two 3.5-inch HDDs and up to four 2.5-inch SSDs (converted from 3.5-inch bays), the CFV235 Mesh offers versatile storage options, providing ample space for storage expansion as needed.
